easy operation and easy maintanence; good quality product
Since 2002, we start to export this kind machines.

Detailed specifications:

Φ65extruder: one

Screw: one

Screw diameter: 65mm

Screw D/M: 28:1

Screw style: special

Reducer unit(Gearbox): one

Control power: 18.5kw

Control style: frequency conversion

Temperature controller: 6

Radiator zones: 4 zones

Electric control cabinet: one

Manul style screen changer: one set

Extruding mould: one ( For extrude two piece strap at same time)

(sizes:  6~15mm)

1m stainless steel cooling water bath: one

Water bath stand: one

Five-roller haul off machine: one

Control power: 1.5kw

Control style: frequency conversion

Dual-tier water stretching bath: one (One bath full of hot water, the other one full of cool water)

Bath stand: one

Dewater vibrator: one

Five-roller haul-off machine: one

Control power: 5.5kw

Control style: frequency conversion

Embossing unit: one

Two-shaft winder: one

Driver: 2HP motor  with a inverter control

Dual coils work alternatively; the coil is token down by hand; the packing is easy (diameter of coil is decided by customers)

Gear motor decides the good winding work.

The counter equipped with a coder is able to alarm automatically when the length of the pipe comes to the set value.

Linear speed: 40-80m/min
